| Temperature range |
-65 to +165°C |
| Characteristic Impedance |
50 Ω |
| Frequency range (with flexible cable) |
0-12.4 GHz |
| Frequency range (with semi-rigid/flexible cable) |
0-18 GHz |
| Voltage Standing Wave Ratio (VSWR, with flexible cable) |
≤1.15 + 0.02F |
| Voltage Standing Wave Ratio (VSWR, with semi-rigid/flexible cable) |
≤1.10 + 0.02F |
| Insulation resistance |
>5000 MΩ |
| Dielectric Withstanding voltage |
1000 V |
| Contact resistance (center conductor) |
<0.003 Ω |
| Contact resistance (outer conductor) |
<0.002 Ω |
| Durability (Life cycles) |
500 Cycles |
