| Parameter | Min | Typ | Max | Units |
|---|---|---|---|---|
| Frequency range | 40 | – | 60 | GHz |
| Gain | 25 | 30 | – | dB |
| Output Psat | 20 | 21 | – | dBm |
| Input VSWR | – | 2.2 | – | :1 |
| Output VSWR | – | 2.2 | – | :1 |
| DC Voltage | – | 5 | – | V DC |
| DC Supply Current | – | 850 | – | mA |
| Parameter | Value | Units |
|---|---|---|
| Input/Output Connector | WR-19/UG-387/U | – |
| DC Bias | Solder Pin | – |
| Size (With Heatsink) | 58×57×48 | mm |
| Weight | – | g |
Taylor Microwave offers DC-110GHz terahertz power amplifier solutions featuring wideband and high output power. These products are widely used in imaging, millimeter-wave communications, millimeter-wave radar, and other applications.
