| Parameter | Value |
|---|---|
| Temperature range | -65 to +165°C |
| Characteristic Impedance | 50 Ω |
| Frequency range (with flexible cable) | 0-12.4 GHz |
| Frequency range (with semi-rigid/flexible cable) | 0-18 GHz |
| Voltage Standing Wave Ratio (VSWR, with flexible cable) | ≤1.15 + 0.02F |
| Voltage Standing Wave Ratio (VSWR, with semi-rigid/flexible cable) | ≤1.10 + 0.02F |
| Insulation resistance | >5000 MΩ |
| Dielectric Withstanding voltage | 1000 V |
| Contact resistance (center conductor) | <0.003 Ω |
| Contact resistance (outer conductor) | <0.002 Ω |
| Durability (Life cycles) | 500 Cycles |
Series SMA connectors are most commonly used, It have the advantages of miniature size, wide frequency range, excellent electrical performances and high reliability. The products have been widely used in the field of micro-wave communication, space, flight and navigation, weapon system and micro-wave measuring equipment.
| Specification | Value |
|---|---|
| Series | SMA |
| Gender | Female |
| Impedance | 50Ω |
| Mounting | Flange |
| Body Plating | Gold |
| Contact Plating | Gold |
| Captivation | No |
| Terminal Type | Post |
Series SMA connectors are most commonly used, It have the advantages of miniature size, wide frequency range, excellent electrical performances and high reliability. The products have been widely used in the field of micro-wave communication, space, flight and navigation, weapon system and micro-wave measuring equipment.
| Specification | Value |
|---|---|
| Series | SMA |
| Gender | Female |
| Impedance | 50Ω |
| Mounting | Flange |
| Body Plating | Gold |
| Contact Plating | Gold |
| Captivation | No |
| Terminal Type | Post |
